NORMA SAE Style Quick Connector 3/4" | 5/8" Hose Barb | 135º
Brand:
NORMA
- Buy 10 for €13,39 each and save 10%
- Buy 25 for €11,90 each and save 20%
- Buy 50 for €10,42 each and save 30%
| Article number: | NOR-7888065019 |
| SKU: | 7888065019 / 1788 8062 019 |
- 2 year warranty
- Delivery time: 2 - 3 weeks
Information
NORMA SAE Style Quick Connector 3/4" | 5/8" Hose Barb | 135º
Specialized plastic quick connectors developed for coolant applications. Test parameters are significantly higher than operation parameters. Special applications possible, contact us!
Media:
For glycol and automotive coolant applications
Operating temperature:
–40°C to 135°C, short term higher
Pressures:
0 to 2 bar positive pressure, partially pulsating (sinusoidal)
Vibrations:
Usually engine vibrations 7–200 Hz, 0.2–20 g
Features:
- Available in three standard profile types (90º, 135° and 180º)
- Designed for SAE J2044 standard spigots
- Internal retainer mechanism for tight-locking seal
- Available with hose barb stem for use with aftermarket hoses & clamps
- Outside spigot diameters: 16mm & 19mm (1/4" – 3/4" available)
Material:
- Housing: PA66-GF33
- Retainer and spacer: PA612
- O-ring: EPDM
SEA Style series:
Product code:
7888065019 - 07888065019 - 788 8065 019 - 0788 8065 019 - 7887065019 - 07887065019 - 788 7065 019 - 0788 7065 019 - 7886065019 - 07886065019 - 788 6065 019 - 0788 6065 019
17888062019 - 1788 8062 019 - 17887062019 - 1788 7062 019 - 17886062019 - 1788 6062 019
Specifications
| Medium: | Coolant |
| Operating Pressure: | 0–2 bar excess pressure |
| Temperature range: | –40°C to +135°C, Short time up to +150°C (approx. 30 min.) |
| Material: | Polyamide Fiberglass (PA66/GF33, PA612) |
| Size: | 3/4" |
| Connection: | 135º |
| Seal: | EPDM |
| Hose connection: | 5/8" |
| Weight: | -- |
