Ideal Worm-drive Clip 12 mm W1
Brand:
Ideal
| Article number: | IDL-12-012-019-W1 |
| SKU: | W1 12 019 |
- 2 year warranty
- Delivery time: 2 - 3 weeks
- Customer service 09:00 - 17:00
Information
Ideal Worm-drive Clip 12 mm W1
All components made of zinc-plated steel. Low level of corrosion resistance. CrVI-free
- Band: Steel, zinc-plated
- Casing: Steel, zinc-plated
- Screw: Steel, zinc-plated, blue passivated
- Screw head type: slotted hex head screw SW 7 mm with integrated Phillips head
Casing:
For IDEAL hose clamps with a diameter of between 20 mm and 45 mm: Band thickness 1.20 mm
For IDEAL hose clamps with a diameter of over 50 mm: Band thickness 1.00 mm
The band steel for the IDEAL hose clamp, which is up to 1.2 mm thick, allows for secure screw and band guidance for the transmission of high forces. As a result, high breaking torques are achieved at the same time at low-level idle torques. In combination with the comparatively low-level friction and the worm drive, this results in high clamping forces.
Threaded bands:
For IDEAL hose clamps with a diameter of between 20 mm and 45 mm: Band thickness 0.80 mm
For IDEAL hose clamps with a diameter of over 50 mm: Band thickness 1.00 mm
High clamping forces can be achieved with these band thicknesses and the stable design of the engraved thread. At the same time, the selected materials ensure a high level of elasticity and therefore a good fit with the external diameter of the hose.
-
All standard applications
-
High clamping force at low band width and low weight
-
Compact design
-
Diameter from 8 mm
-
Standard programme available from stock
Product code:
W1 12 020 - W1 12 022 - W1 12 025 - W1 12 027 - W1 12 032 - W1 12 035 - W1 12 040 - W1 12 040 - W1 12 045 - W1 12 050 - W1 12 060 - W1 12 070 - W1 12 080 - W1 12 090 - W1 12 100 - W1 12 110 - W1 12 120 - W1 12 130 - W1 12 140 - W1 12 150 - W1 12 160 - W1 12 170 - W1 12 180 - W1 12 190 - W1 12 200 - W1 12 210 - W1 12 220 - W1 12 230 - W1 12 240 - W1 12 250 - W1 12 260 - W1 12 270 - W1 12 280 - W1 12 290 - W1 12 300 - W1 12 310 - W1 12 320 - W1 12 330
Specifications
| Bolt: | SW - 7 mm |
| Bandwidth: | 12 mm |
| Tightening torque (Maximum): | 4 Nm (Maximum) |
