PARI Power Clamp W1 - 20 mm single bolt
Brand:
Powerflex
| Article number: | PWF-W1-1D-20-031-035 |
| SKU: | PWF-W1-1D-20-031-035 |
- 2 year warranty
- Delivery time: 1 week after order date
Information
PARI Power Clamp W1 - 20 mm single bolt
Power-Clamps are designed for heavy-duty industrial hose connections. The 20-1-1 Power-Clamp is configured with one bolt and is fitted with a bridge with raised edges, which prevent shearing of the hose material.
The 20-1-1 Power-Clamp is suitable for many applications.
Material:
- Screw: M6 x 45, DIN 912, W1 (8.8)
- Band 20 mm width, 1mm thick, DIN 1623 W1 (St.12.03) White gegalvanized (Cr3)
Typical applications can be found in the following areas:
- Agricultural
- Drainage systems
- Irrigation systems
- Cooling systems
- Sludge suction systems
Product code:
20-1-1-035 - 20-1-1-038 - 20-1-1-040 - 20-1-1-043 - 20-1-1-045 - 20-1-1-050 - 20-1-1-055 -
20-1-1-060 - 20-1-1-065 - 20-1-1-070 - 20-1-1-075 - 20-1-1-080 - 20-1-1-085 - 20-1-1-090 -
20-1-1-095 - 20-1-1-100 - 20-1-1-105 - 20-1-1-110 - 20-1-1-115 - 20-1-1-120 - 20-1-1-125 -
20-1-1-130 - 20-1-1-135
Specifications
| Bolt: | M6 x 45 |
| Bandwidth: | 20 mm |
| Tightening torque (Maximum): | 10 Nm (Maximum) |
