Oetiker Universal Worm Drive Clamp W4
Brand:
Oetiker
- Buy 50 for €5,11 each and save 5%
- Buy 100 for €4,84 each and save 10%
- Buy 150 for €4,57 each and save 15%
| Article number: | OTK-18000211 |
| SKU: | 18000211 |
- 2 year warranty
- Delivery time: Delivery in 1 to 2 days
Information
Oetiker Universal Worm Drive Clamp W4 (AISI 304) with Hex Screw for 8 and 12 mm Band
Screw Clamp design Flap lock
After opening the body, the band can be formed by hand to approximately the clamping diameter. The flap can then be closed, and the clamp tightened by turning the screw. As a result, the screw only has to be turned for the last part of the clamping operation.
Intermediate stop
The flap is secured by an intermediate stop. Even when loosely assembled, clamps cannot open on their own accord.
Visual overload protection
The housing incorporates a web which distorts visibly above a tightening torque of 4–5 Nm (35–44 in-lbs). This visual feature indicates that a Worm Drive Clamp is optimally tightened and still has an adequate factor of safety to the maximum tightening torque.
Worm Drive Clamps with wing screw
The Worm Drive Clamp with wing screw can be installed entirely without tools. The integral, torsionally-stiff wing provides optimum grip. The dimensions correspond to the standard design with the exception of the wing screw.The universal tension band is available in 8 or 12 mm band width, each on rolls with lengths of 10, 20, or 30 m, with a suitable lock for band widths of 8 or 12 mm.
Assembly Recommendations
For safe tightening of screw clamps without wing screws, we recommend use of a 5A/F hexagon wrench. The maximum static tightening torque is 6 Nm (53 in-lb).
Installing an Universal Worm Drive Clamp
Measure the circumference to be clamped and cut off the band to that length. Pass the end of the band, from above, through the slit in the closing element, and fold it back at least 40 mm below the band. Pass the second end of the band through the slit in the perforated part of the closing element and fold it back at least 40 mm. Lay the band around the part to be clamped, push the band end with perforation below the flap lock and close.
The Oetiker Universal Clamp Band must be ordered separately!!
(This universal tension band is available in our shop in 8 or 12 mm band width, each on rolls with lengths of 10, 20, or 30 m.)
Specifications
| Bolt: | SW 5 mm Allen Screw or Wing Screw |
| Bandwidth: | 12 mm |
| Tightening torque (Maximum): | 6 Nm (Maximum) |
