Oetiker Adjustable Ear Clamps 109
Brand:
Oetiker
| Article number: | OTK-10900012 |
| SKU: | 10900012 |
- 2 year warranty
- Delivery time: 2 - 3 weeks
Information
Oetiker Adjustable Ear Clamps type 109 - W1
The lock consists of two hooks that can withstand tensile loads during and after closing and a locking tab, designed to keep the hooks in their windows before closing. This locking design allows for hooking in different positions within the range of the clamp and a range of diameters can be covered by a single clamp.
The Oetker 1-ear Boot Clamp 109 are supplied preformed and attached on center diameter.
Each locking step of the interlock reduces the closure diameter by approximately 1.6mm.
For detailed technical information, read the PDF below.
General recommendations
The ears of these clamps are closed with the recommended uniform force (so-called force priority). This method results in a constant, reproducible stress within the clamp material, without overloading either the clamp or the parts assembled. The nominal diameter of the clamp must always be chosen that, when installed with the correct clamping force, the ears are nearly closed. Complete process monitoring and 100% process documentation are available via the "Electronically Controlled Pneumatic Power Tool" Oetiker ELK.
Certificates / Documentation:
Certificates and documentation are available for these products. If desired, you can order these together with your order.
We can offer:
- Certificate of Conformity (CoC)
- EN 10204 3.1 Inspection Certificate
Certificates must be requested at the time of ordering. Certificates requested after shipment may incur additional administrative costs and cannot always be provided retrospectively.
You will find the certificates at the bottom of the drop-down order menu at the top right of this page.
Generally, a subsequent order is significantly more expensive due to the administrative burden.
Product code:
10900012 - 10900013 - 10900014 - 10900015 - 10900016 - 10900017 - 10900018 - 10900019 - 10900020 - 10900021 - 10900022 -10900023
Specifications
| Bolt: | -- |
| Bandwidth: | 7 + 9 mm |
| Tightening torque (Maximum): | -- |
