CPC - NS2D170212 | NS212 Coupling Body | Polypropylene | Hose barb 3,2 mm (1/8")

€11,84 Incl. tax
€9,78 Excl. tax
* Excl. tax | Excl. Shipping costs
Now 0 in stock
Delivery time: 2 - 3 weeks
Article number: CPC-NS2D170212
SKU: NS2D170212
  • 2 year warranty
  • Delivery time: 2 - 3 weeks
Information

CPC - NS2D170212 | NS212 Coupling Body | Polypropylene | Hose barb 3,2 mm (1/8")


This In-Line NS212 Series coupling features a non-spill valve in a compact size, at a great price. Use the NS212 when even a few drops pose problems regarding safety, media cost or environmental regulations. This innovative coupling is lightweight, chemically resistant and easy to use.

The non-spill design effectively eliminates spills, minimizes downtime and enhances operator safety.

Note: The NS212 does NOT mate NS2.

NS212 Series couplings were built on the company’s proven platform of non-spill valves designed to provide fast, safe and leak-free fluid line connections. The NS212 is an easy, twist-to-connect coupling with an integrated locking mechanism and double-sided non-spill shutoff valves. It is also chemically resistant and ideal for a diverse range of applications including printing and ink management, analytical instrumentation, electronic cooling and chemical handling. NS212 couplings provide high-flow fluid transfer in a small footprint.

Characteristics and benefits:
  • Non-spill design: No spills with disconnection under pressure
  • Multiple seal materials; Broad chemical compatibility for diverse applications
  • Glass-filled polypropylene: Durable and compatible to many chemicals
  • Twist-to-connect locking; Easy, non-spill connections in tight spaces
  • Ultra low air inclusion; Minimizes contaminants, reduces the need to spurge lines

Possible areas of application:
  • Printer and ink management
  • Analytical instrumentation
  • Electronic cooling circuits
  • Chemical handling

Materials:
  • Main components and valve: Glass-filled polypropylene
  • Valve Spring: AISI 316 Stainless Steel (W5)
  • 0-ring: EPDM (optional FKM/Simriz® FFKM)
  • Colour: Gray

Specifications:
  • Working pressure: vacuum up to 3.1 bar (45 PSI)
  • Operating Temperature: 0ºC to 49ºC (32ºF to 120ºF)
  • Spillage: 0,025 ml per disconnection
  • Inclusion: 0,009 cc per connect
  • Flow Capacity: Cv ~ 0,45

Look at related products for the right choice for your application or contact our sales department: [email protected]


Specifications
Medium: Liquid / Air / Chemicals
Operating Pressure: 3,1 bar Vacuum
Temperature range: 0° C tot +49° C
Material: Polypropylene
Size: --
Connection: In-line Coupling Body
Seal: EPDM
Hose connection: 3,2 mm (1/8") Inner diameter
Weight: --
CPC CPC - NS2D170212 | NS212 Coupling Body | Polypropylene | Hose barb 3,2 mm (1/8")
