IQ-Parts Ferrules DIN32676 | sched. A | Long (KL) | AISI 316L
Brand:
IQ-Parts
| Article number: | IQP-20411985 |
- 2 year warranty
- Delivery time: 1 week after order date
- Customer service 09:00 - 17:00
Information
Ferrules DIN32676 | sched. A | Long (KL) | AISI 316L
Ferrules DIN32676 Clamp connections are ideal for use in the food, pharmaceutical, chemical and biological industries. These clamp connections according to DIN32676 are also suitable in the field of engine and test bench construction.
Characteristics:
- Material: Stainless steel AISI 316L (corresponding to 1.4404)
- Flange sleeve in different versions: according to DIN32676 Series A/B/C in version KK (Short) and KL (Long), ISO 2852, EN ISO 1127, special sizes, BS 4825, etc.
- Standard interface: H3 hygiene class, inside <0.8 µm, outside <1.6 µm
In addition to the flange sleeves and blind covers according to DIN32676, we also offer you the right seals in different sealing materials and cast brackets in different designs. See the related products for this.
Take a good look at the PDF of the desired clamp to order the right size clamp with the right ferrules!!
|
sched. A DN Metric |
Tube OD A |
Tube ID B |
Flange OD C |
Groove D |
Long (KL) E |
Item-No. |
|
DN06 |
8,0 |
6,0 |
25,0 |
20,2 |
28,6 |
20411985 |
|
DN08 |
10,0 |
8,0 |
25,0 |
20,2 |
28,6 |
20411995 |
|
DN10 |
13,0 |
10,0 |
34,0 |
27,5 |
28,6 |
20412005 |
|
DN15 |
19,0 |
16,0 |
34,0 |
27,5 |
28,6 |
20412055 |
|
DN20 |
23,0 |
20,0 |
34,0 |
27,5 |
28,6 |
20412105 |
|
DN25 |
29,0 |
26,0 |
50,5 |
43,5 |
36,0 |
20412155 |
|
DN32 |
35,0 |
32,0 |
50,5 |
43,5 |
36,0 |
20412205 |
|
DN40 |
41,0 |
38,0 |
50,5 |
43,5 |
36,0 |
20412255 |
|
DN50 |
53,0 |
50,0 |
64,0 |
56,5 |
36,0 |
20412305 |
|
DN65 |
70,0 |
66,0 |
91,0 |
83,5 |
48,0 |
20412355 |
|
DN80 |
85,0 |
81,0 |
106,0 |
97,0 |
48,0 |
20412405 |
|
DN100 |
104,0 |
100,0 |
119,0 |
110,0 |
48,0 |
20412455 |
|
DN125 |
129,0 |
125,0 |
155,0 |
146,0 |
66,0 |
20412505 |
|
DN150 |
154,0 |
150,0 |
183,0 |
174,0 |
66,0 |
20412555 |
|
DN200 |
204,0 |
200,0 |
233,5 |
225,0 |
66,0 |
20412605 |
Dimensions in mm, Letters A, B, C, D and E correspond to the photo of the technical drawing
product code:
20411985 - 20411995 - 20412005 - 20412055 - 20412105 - 20412155 - 20412205 - 20412255 - 20412305 - 20412355 - 20412405 - 20412455 - 20412505 - 20412555 - 20412605
